Tripp Lite UPS Backup by Eaton

Reliable power protection for home offices, AV systems, and edge IT. Tripp Lite units combine automatic voltage regulation (AVR), surge suppression, and battery backup, with options for pure sine wave output, short-depth rackmounts, and hot-swappable batteries.

When to Choose It

• Use for desktops with active-PFC power supplies, studio/AV gear, PoE switches, NAS, small servers, and network closets that need clean power and short-to-medium runtime.
• Choose pure sine models for sensitive electronics and modern PCs to avoid buzz, heat, or unexpected shutdowns on stepped waveforms.
• Choose online double-conversion for noisy generator power, medical/measurement devices, or mission-critical edge compute that benefit from continuous isolation from the grid.

Topologies at a Glance

• Standby or basic line-interactive: Budget-friendly protection for modest loads; AVR stabilizes voltage to reduce battery use.
• Line-interactive sine wave: Clean output suitable for active-PFC PSUs and AV gear; short transfer time typically tolerated by most electronics.
• Online double-conversion: Continuous power conditioning with no transfer; best for sensitive or critical equipment and unstable sources.

Size It in Four Steps

1. List your concurrent loads in watts. Example: desktop 350 W, 27 in display 40 W, router + modem 20 W, NAS 30 W = 440 W.
2. Add headroom of about 25% for spikes and future devices: 440 W × 1.25 ≈ 550 W.
3. Pick by watts, not only VA. Ensure the UPS watt rating meets or exceeds your target (for example, a 1500 VA unit typically supports about 900–1000 W, model-dependent).
4. Decide runtime. Aim for 7–10 minutes to save work and shut down, 15–30 minutes to ride out brief outages, or longer if powering only networking gear.

Feature Highlights

• AVR buck/boost smooths brownouts and overvoltage without draining batteries, extending battery life.
• Pure sine wave models support active-PFC PCs, studio monitors, mixers, and UPS‑sensitive chargers.
• USB/HID and optional SNMP enable graceful shutdowns and remote monitoring.
• Controllable outlet groups shed nonessential loads to extend runtime for core devices.
• Hot-swappable batteries (model-dependent) allow replacement without taking systems offline.
• Data line protection on select models helps guard Ethernet or coax paths.

Quick Setup Checklist

1. Install where there is airflow; avoid sealed cabinets and heat sources.
2. Connect only essential devices to battery-backed outlets; use surge-only for printers or speakers.
3. Connect the USB cable and enable OS or vendor software for safe shutdown at a chosen runtime threshold.
4. Label outlets and cables for faster troubleshooting during an outage.
5. Optionally add an SNMP card for racks or remote sites.

Runtime Examples

Deployment Notes

Home Office

Use a line-interactive sine wave tower. Put the PC, monitor, and networking on battery outlets; set automatic shutdown when 5–7 minutes remain.

AV Rack

Select a short-depth sine wave rackmount. Enable AVR to ride through dimming events; put consoles, receiver, and network on battery, and leave amplifiers or subwoofers on surge-only.

Network Closet

Short-depth rack units fit shallow wall cabinets. Prioritize firewall, core switch, and ISP gear on battery; shed guest Wi‑Fi or signage using outlet groups.

Maintenance and Safety

• Test monthly by briefly unplugging utility power and verifying shutdown settings and alarms.
• Keep vents clear; heat shortens battery life. VRLA batteries typically last 3–5 years depending on temperature and usage.
• Avoid laser printers, heaters, or vacuums on battery outlets due to high inrush current.
• Do not daisy-chain surge strips or other UPS units into the UPS; plug directly into a properly grounded outlet.
• Update firmware/software when available to improve battery gauging and event handling.

Alternatives and Compatibility Notes

• If you frequently run on generators or have especially noisy power, prefer online double-conversion.
• Active-PFC desktop? Choose pure sine wave models to prevent shutdowns under load spikes.
• Need longer runtime? Consider a larger VA/watt model, reduce connected load to essentials, or select models that support external battery packs (where available).

FAQ

• Do I need pure sine wave? If you use an active-PFC PC, studio gear, or sensitive AV equipment, choose pure sine wave for best compatibility.
• How do I estimate runtime? Use the UPS vendor chart for your model and your measured watt load; plan to keep only essentials on battery.
• Can I put this in a shallow rack? Yes, many Tripp Lite rack units are short-depth for wall or AV cabinets; check dimensions and rail compatibility.
• What about battery replacement? Most models use field-replaceable VRLA batteries; note the install date and plan for replacement in about 3–5 years.
• Will it mute alarms? Many models allow alarm muting while retaining on-screen warnings; consult the front panel menu or software.
